MFD/CHARTPLOTTER COMPATIBILITY MATRIX

Liquid Optics is compatible with major brand MFDs.

In most cases, your MFD must have an analog video input to receive and display the video feed. Additionally, HDMI inputs can be used in conjunction with an RCA to HDMI converter.

Is your MFD not listed? Please send us the model number at info@liquidoptics.com.au and we’ll confirm compatibility for you.

GARMIN	SIMRAD / NAVICO	RAYMARINE	HUMMINBIRD	FURUNO	LOWRANCE
GARMIN GPSMAP 1042, 1222, 1242, 1243, 7410, 7412, 7416, 7607, 7610, 7612, 7616, 8212, 8215, 8410, 8412, 8422, 8610, 8612, 8616, 8617, 8622, 8624, 8700 Compatible via BNC composite port (labeled CVBS IN or VIDEO)	SIMRAD / NAVICO All NSS models, B&G Zeus (not Glass Helm, see next line) Compatible via 8-pin video port and adapter cable. Manufacturing part number: 000-00129-001. “Simrad NSE/NSS Video/Data Cable”	RAYMARINE Axiom XL Compatible via adapter cable, part number A80235 Also compatible via PWR/Video/NMEA 0183 port and Raymarine cable, part number R62379	HUMMINBIRD APEX 13 Mega SI+ Fishfinder/ Chartplotter No analog video input. Compatibility possible via HDMI converter.	FURUNO Furuno TZ Touch 2: 12”, 15” Compatible via analog video inputs.	LOWRANCE HDS 9, 12, 16 Compatible via adapter cable. HDS Video Adapter Cable SKU: 000-11010-001
GARMIN GPSMAP 741, 742, 752, 942, 943, 952 AQUAMAP 1022, 1052, 1222, 1252 Compatible via BNC composite port (labeled CVBS IN)	SIMRAD / NAVICO NSO, B&G Zeus Glass helm (GH) systems (all models, both black box and MFDs) Compatible via two BNC connectors on the unit	RAYMARINE Axiom Pro 9, Axiom Pro 12, C97, E95, E125, E127, E165, gS95, gS125, gS165, es97 Compatible via PWR/Video/NMEA 0183 port and Raymarine cable, part number R62379	HUMMINBIRD Not compatible (no analog inputs): HELIX 5, 7, 9, 10, 12 SOLIX 10, 12, 15	FURUNO Furuno TZ Touch 3: 12”, 16”, 19” Compatible via analog video inputs.	LOWRANCE Not compatible (no analog inputs): Elite FS 7, 9
GARMIN GPSMAP 4210, 5012, 5212, 5215, 6008, 6012, 6208, 6212, 7012, 7015, 7212, 7215 Compatible via VIDEO port and 17-pin video adapter cable, Garmin part number 010-11425-00	SIMRAD / NAVICO MO/ GH monitors (monitors that ship with the NSO / Zeus GH black box processors) Compatible via two BNC connectors on the unit Displayed outside of MFD software i.e by changing input source	RAYMARINE eS75, 78 HybridTouch Compatible via Video/NMEA 0183 cable (SKU# RAY-R70414)	HUMMINBIRD	FURUNO Furuno NavNet 3D 12″ Compatible via RCA inputs	LOWRANCE Newer Lowrance models may require a software update to enable video input.
GARMIN Not compatible (no analog inputs): ECHOMAP™ UHD 73sv, 74sv, 94sv ECHOMAP™ Ultra 102sv, 106sv, 126sv GPSMAP 840, 1020, 1040 CR 1522, CS 1522	SIMRAD / NAVICO Not compatible (no analog inputs): NSX 3007, 3009, 3012 GO series (GO7, 9, 12)	RAYMARINE C90W Compatible via Pwr/Data port and Raymarine cable, part number R62227	HUMMINBIRD	FURUNO Not compatible: TZ Touch 3 9” TZ Touch 2 Black Box (requires NTSC to PAL converter)	LOWRANCE
GARMIN MFDs on the Garmin Marine Network are capable of sharing video inputs from one networked MFD to another	SIMRAD / NAVICO	RAYMARINE Not compatible (no analog inputs): Axiom 7, 9 ,12 Axiom+ 7, 9, 12 E120 Classic	HUMMINBIRD	FURUNO	LOWRANCE
